본 문서에서는 Tibero Java Gateway을 이용한 Tibero to PostgreSQL DB Link 설정 및 테스트 환경 구축을 위한 PostgreSQL 설치 방법을 안내합니다.

테스트 구성 환경

OS	PostgreSQL	Java Gateway	Tibero
Version : Red Hat Enterprise Linux Server release 7.4IP : 192.168.0.180​​	Version : PostgreSQL 12.3OS user : postgresDB name : testDB user : pgPort : 5432​	Port : 9099​​​​​	Version : Tibero 6 (DB 6.0 FS07_CS_1912)OS user : namDB name : tiberoDB user : namPort : 18629

DBLink 설정 및 확인

1. Java Gateway

1.1. tbJavaGW.zip 압축 해제

[nam@www:/home/nam/tibero6/client/bin]$ unzip tbJavaGW.zip

Archive: tbJavaGW.zip

  creating: tbJavaGW/

  creating: tbJavaGW/lib/

inflating: tbJavaGW/jgw.cfg

inflating: tbJavaGW/jgw_service.bat

inflating: tbJavaGW/jgwlog.properties

inflating: tbJavaGW/lib/commons-collections.jar

inflating: tbJavaGW/lib/commons-daemon-1.0.6.jar

inflating: tbJavaGW/lib/commons-pool.jar

inflating: tbJavaGW/lib/log4j-1.2.15.jar

inflating: tbJavaGW/lib/tbgateway.jar

inflating: tbJavaGW/tbgw

1.2. Java Gateway 설정

[nam@www:/home/nam/tibero6/client/bin/tbJavaGW]$ vi jgw.cfg

# Target database

DATABASE=POSTGRESQL

# Datasource class name for target database

# use with DATABASE=JDBC30 option.

#DATASOURCE_CLASS_NAME=com.tmax.tibero.jdbc.ext.TbDataSource

# XA datasource class name for target database

# use with DATABASE=JDBC30 option.

#XA_DATASOURCE_CLASS_NAME=com.tmax.tibero.jdbc.ext.TbXADataSource

# Listener port

LISTENER_PORT=9099

# Initial thread pool size

INIT_POOL_SIZE=10

# Max thread pool size

MAX_POOL_SIZE=100

# Max cursor cache size per thread

MAX_CURSOR_CACHE_SIZE=100

# Gateway Encoding-“ASCII”, “EUC-KR”, “MSWIN949”, “UTF-8”, “UTF-16”, “SHIFT-JIS”

ENCODING=MSWIN949

# Max length for Types.LONGVARCHAR

MAX_LONGVARCHAR=4K

# Max length for Types.LONGRAW

MAX_LONGRAW=4K

1.3. Postgres JDBC 업로드

아래 링크를 참고해 JDK 버전에 맞는 JDBC를 사용합니다.

https://jdbc.postgresql.org/download/

[nam@www:/home/nam/tibero6/client/bin/tbJavaGW/lib]$ ls -al

total 3028

drwxr-xr-x 2 nam dba 4096 Nov 4 13:44 .

drwxr-xr-x 4 nam dba 4096 Nov 5 09:46 ..

-rw-r–r– 1 nam dba 559366 Dec 8 2020 commons-collections.jar

-rw-r–r– 1 nam dba 24019 Dec 8 2020 commons-daemon-1.0.6.jar

-rw-r–r– 1 nam dba 42492 Dec 8 2020 commons-pool.jar

-rw-r–r– 1 nam dba 391834 Dec 8 2020 log4j-1.2.15.jar

-rw-r–r– 1 nam dba 906887 Nov 3 15:11 postgresql-42.2.8.jre7.jar

-rw-r–r– 1 nam dba 483205 Dec 8 2020 tbgateway.jar

1.4. tbgw 수정

[nam@www:/home/nam/tibero6/client/bin/tbJavaGW]$ vi tbgw

#! /bin/sh

#Classpath

commonsdaemon=./lib/commons-daemon-1.0.6.jar

commonspool=./lib/commons-pool.jar

commonscollections=./lib/commons-collections.jar

log4j=./lib/log4j-1.2.15.jar

msjdbc=./lib/sqljdbc.jar:./lib/sqljdbc4.jar

asejdbc=./lib/jconn3.jar

postgresqljdbc=./lib/postgresql-42.2.8.jre7.jar

gateway=./lib/tbgateway.jar

#log4j properties

#log4jfile must be exists on classpath

log4jfile=jgwlog.properties

#Main Class

mainclass=com.tmax.tibero.gateway.main.GatewayMain

configfile=./jgw.cfg

if [[ $# -gt 0 ]] && [[ $1 = “-v” ]] ; then

   java -jar $gateway

else

                  java -Xms128m -Xmx512m -Dlog4j.configuration=$log4jfile -classpath

$commonsdaemon:$commonspool:$commonscollections:$log4j:$gateway:$msjdbc:$asejdbc:

$postgresqljdbc:.​ $mainclass CONFIG=$configfile $* &

     sleep 1

fi

1.5. tbgw 실행

[nam@www:/home/nam/tibero6/client/bin/tbJavaGW]$ ./tbgw

——————————-

Name : TmaxData JAVA GATEWAY
Database: 5
Port : 9099
——————————-

☞ “[Tibero] DBLINK 설정_Tibero to PostgreSQL (2)”에서 계속됩니다.​​

​
